NOYES M210 Dual Wavelength OTDR – Multimode 850/1300nm (Adapters – 1 SC, 1 FC)

NOYES M210 Dual Wavelength OTDR – Multimode 850/1300nm (Adapters – 1 SC, 1 FC)

AFL NOYES M200 offers unmatched OTDR capabilities in a handheld package weighing less than 1 kg (2 lb). Multimode, Singlemode, and ‘QUAD’ wavelength models are offered.

With short dead zone and intermediate range specifications, the M200 is ideal for Tier 2 testing of premises (building and campus) networks or certification and troubleshooting of FTTx PON networks. And its bright, transflective display makes it suitable for both indoor and outdoor operation.

The M200 is based on a new hardware/software platform that supports automatic and manual setup, precision event analysis, dual-wavelength testing, rich file naming and folder setup, internal and removable media data storage, and USB connectivity. Test ports are equipped with tool-free adapters, which can be changed in seconds. A custom-designed polycarbonate case and shockabsorbing boot make it our most rugged OTDR ever.

Applications:

• Tier 2 testing of premises networks
• FTTx PON certification and troubleshooting
• Fast fault location
• Splice verification
• Network documentation
• ST, SC, FC Adapter Included
• Full Auto OTDR – document installation and fault locate
• Expert OTDR – document and fault locate using Auto or Auto Once
• Real-Time OTDR – locate faults and verify splices
• Visibly Fault Locate – locate bends and breaks and verify polarity

Features:

• Hand-held, lightweight – 0.9 kg (2 lb)
• Inspection capable
• >8 hours battery life
• Touch and Test user interface
• TRM reporting software
• Automatic Pass/Fail analysis (TIA/ISO)
• Internal and USB storage (1000s of tests)
• Dynamic Range – 22dB (Multimode), 26dB (Single Mode)
• 1.5 Meter Event Dead Zone (Typical)
• Integrated VFL (650nm)
• Li-Ion battery (6 hour life)
• Transflective (indoor/outdoor) Touchscreen Display
• USB Flash and Host Ports
• Compact Flash TM MemorycarMemory Card
• ST, SC, FC Adapter

Kit Includes:

• NOYES M200 OTDR
• A rugged, soft-sided carry case with shoulder strap
• 110/220v AC power adapter with country-specific power cord
• User guide
• Various adapters

Download Product Spec Sheet:

• Spec Sheet

• AFL NOYES M Series OTDR User’s Guide (PDF)

• AFL OTDR Testing Quick Reference Guide (PDF)
